Both in-line capabilities and secondary operations allows for the right mix of services for your custom steel tubes. Other adjacent process technologies include custom roll forming services, various welding capabilities and laser cutting. We can accommodate mandrel bending, draw bending, roll bending and hydraulic sweep bending. Bending steel tubing is just one of the many additive manufacturing services we offer. Roll Forming Corporation has roll forming and custom metal bending services all under one roof.
Steel Tube Bending Solutions + Roll Forming Under One Roof We offer other steel tube bending capabilities including fabrication bending, hydraulic sweep, roll bending, draw bending and mandrel bending services. You can choose from one of our standard tube designs, or we can customize a tube to meet your specific requirements.
#Tube bending professional#
If you require any professional advice or if you have a project in mind, please do not hesitate to contact the metal fabrication experts.With electric servo driven multi-stack CNC tube bending capabilities, welded steel cut tubes can bend with repeatability and tighter tolerances. The yield point is the point at which the tube or pipe will deform permanently during the bending process. The centre line radius (CLR) refers to the radius along the tube or pipe’s neutral axis.Īn S-curve is the term used when bends occur in opposite directions in the same plane. A minimum straight length is needed between each bend. Straights between bends refers to a part that requires multiple bends.
The degree of bend is the angle of the bend – measured on the outside. This can also be called the schedule in a pipe or the gauge in a tube. The wall thickness (W/T) is the measurement between the exterior and interior surfaces of the tube or pipe. The inside diameter (I/D) is the distance measured across the widest part of the inside opening of the tube or pipe. The outside diameter (O/D) is the distance across the widest area of the tube or pipe. The metal is formed into the bend design by the lower rollers pushing against the feed path. This allows it be shaped to a large centre line radius.
#Tube bending series#
A piece of tube or pipe is passed through a series of three rollers in a pyramid formation. Roll bending is used when large radius bends or curves are needed. It is the most commonly-used form of bending. It is used in particular with thinner wall materials, as it helps to prevent defects – such as flattening, rippling or collapse – in the bend. Mandrel bending is carried out by placing a mandrel inside the pipe or tube that’s being bent. It does not involve the use of a mandrel. It involves the tube being clamped in place, while a pressure die moves around the radius to create a bend. However, there are some aspects to consider before performing this operation. In fact, tube bending is considered the main operation to form tubing and piping as the final product or as part of a system. Also called compression forming, this technique is the original method of bending tubes. Tube bending is one of the most common forming processes when it comes to manufacturing metal parts for different industries. An understanding of the terminology used within the tube and pipe bending industry will help you to better comprehend the basics:Ĭompression bending is a method of bending pipes or tubes when the die in place remains stationary, while a counter die is used to bend the material round the stationary die.
